HomeFibercement Board
Fibercement Board
A1 Class (EN 13501-1, CE certicated) Fire Resistant Material Fibercement which is cellulose fiber reinforced, cement and silica based, autoclaved board, is produced by one of HEKIM HOLDING’s companies in Turkey. There are three main products in the product range. HEKIMBOARD sheets are used as facade cladding material and backer board in construction sector.These sheets are produced as wooden, natural stone, non-aligned brick, stone masonary, slate masonary, grooved wooden, groved smooth, groved natural stone textured. TURKSIDING planks are used as indoor and outdoor cladding material as overlapped application. The third production group is paper or polypropylene foil laminated fibercement boards which are marketed under the brand name ofFIBERCEMENTLAM. The fibercement products are mostly consumed in domestic market and exported to many countries as directly as sheets and sidings or as a component of final products such as prefabricated buildings and containers.
+ HekimBoard Fibercement Flat Sheets
| Product Type | : | Autoclaved fiber cement flat sheet |
| Material Properties | : | Resistant to weather conditions, easily handled with hard wood processing tools. |
| Dimensions | : | 1250×2500 mm – 1250×3000 mm |
| Thickness | : | 6 – 8 – 10 – 12 – 14 – 16 – 18 – 20 mm |
| Tolerance on length | : | ±5 mm |
| Tolerance on width | : | ±3,75 mm |
| Tolerance on thickness | : | ± 10 % e – smooth sheet – 10 % e / +15 % e – textured sheet (e: sheet thickness) |
| Squareness of edges | : | ±2 mm /m |
| Straightness of edges | : | ± %0,1 a (a: sheet length or width) |
| Surface appearance | : | Smooth or textured (cedar texture) |
| Apparent density | : | 1350 ± 50 kg/m3 |
| Frost Resistance | : | Frost resistant according to TS EN 12467 |
| Water impermeability | : | Impermeable according to TS EN 12467 |
| Diffusion resistance number | : | μ ≤ 20 |
| Modulus of rupture (smooth sheet) | : | 18,0 N/mm2 (machine direction=longitudinal): 12,0 N/mm2 (transverse to machine direction) |
| Modulus of rupture (textured sheet) | : | 15,0 N /mm2 (machine direction=longitudinal): 10,0 N/mm2 (transverse to machine direction) |
| Pressure strength | : | 30,0 N /mm2 (perpendicular to sheet surface) |
| Tensile strength | : | 2,0 N /mm2 (perpendicular to sheet surface) |
| Frost Resistance | : | Frost resistant according to TS EN 12467 ( waterboard ) |
| Reaction to fire | : | Fire resistant, A1 Class building material according to EN 13501-1 |
| Release of asbestosı | : | Non-asbestos |
| Release of other dangerous substances | : | None |
| Thermal expansion coefficient | : | t: 0,005 mm/Mk |
| Thermal conductivity coefficient | : | λ 0,18 W/Mk |
| Modulus of elasticity | : | 8000 N/mm2 (machine direction) 6000 N/mm2 (transverse to machine direction) |
| Water absorption ratio | : | < % 30 ( full saturation, including ambient moisture ) |
| Moisture in storage | : | < % 10 (subject to ambient moisture) |
| Hygrical movement | : | 0,5 mm / m (full saturation) |
| Bending radius | : | 12 m |
+ Turksiding Fibercement Planks
| Product Type | : | Autoclaved fiber cement planks |
| Material Properties | : | Resistant to weather conditions, easily handled with hard wood processing tools |
| Dimensions | : | 180 x 2500mm veya 210 x 2500 mm |
| Thickness | : | 8 -10 mm |
| Tolerance on length | : | ±5 mm |
| Tolerance on width | : | ±3,75 mm |
| Tolerance on thickness | : | ± %10 e (smooth plank) – %10 e / + 15 % e (Smooth Sheet) (e: sheet thickness) |
| Squareness of edges | : | ±2 mm /m |
| Straightness of edges | : | ± %0,1 a (a: sheet length or width) |
| Surface appearance | : | Smooth or textured (cedar texture) |
| Apparent density | : | 1350 ± 50 kg/m3 |
| Frost Resistance | : | Frost resistant according to TS EN 12467 |
| Water impermeability | : | Impermeable according to TS EN 12467 |
| Diffusion resistance number | : | µ=250 |
| Modulus of rupture (smooth sheet) | : | ~ 18,0 N/mm2 (machine direction=longitudinal) ~ 12,0 N/mm2 (transverse to machine direction) |
| Modulus of rupture (textured sheet) | : | ~ 15,0 N/mm2 (machine direction=longitudinal) ~ 10,0 N/mm2 (transverse to machine direction) |
| Pressure strength | : | 30,0 N /mm2 (perpendicular to sheet surface) |
| Tensile strength | : | 2,0 N /mm2 (perpendicular to sheet surface) |
| Reaction to fire | : | Fire resistant, (A1 Class building material according to EN 13501-1) |
| Release of asbestosı | : | Non-asbestos |
| Release of other dangerous substances | : | None |
| Thermal expansion coefficient | : | t: 0,005 mm/Mk |
| Thermal conductivity coefficient | : | λ 0,18 W/Mk |
| Modulus of elasticity | : | 8000 N /mm2 (machine directionl) 6000 N/mm2 (transverse to machine direction) |
| Water absorption ratio | : | < % 30 ( full saturation, including ambient moisture ) |
| Moisture in storage | : | < % 10 (subject to ambient moisture) |
| Hygrical movement | : | 0,5 mm / m (full saturation) |
| Bending radius | : | ~ 12 m |
+ Fibercement Lam
| Product Type | : | These are autoclaved paper and polypropylene foil laminated fibercement sheets |
| Material Properties | : | Resistant to weather conditions, easily handled with hard wood processing tools |
| Lamination Material | : | Polypropylene (Alkorcell) or imprenated paper foil. |
| Dimensions | : | 1250 x 2500mm veya 1250 x 3000 (azami 3150 mm) |
| Thickness | : | 6 – 20 mm |
| Tolerance on length | : | ±5 mm |
| Tolerance on width | : | ±3,75 mm |
| Tolerance on thickness | : | %10 e (smooth sheet) – %10 e / + 15 % e (textured sheet) (e : sheet thicknessı) |
| Squareness of edges | : | ±2 mm /m |
| Straightness of edges | : | ± %0,1 a (a: sheet length or width) |
| Surface appearance | : | Smooth or textured (cedar texture) |
| Apparent density | : | 1350 ± 50 kg/m3 |
| Frost Resistance | : | Frost resistant according to TS EN 12467 |
| Water impermeability | : | Impermeable according to TS EN 12467 |
| Diffusion resistance number | : | µ=250 |
| Porosity | : | % 30 |
| Modulus of rupture (smooth sheet) | : | 18,0 N /mm2 (machine direction=longitudinal) : 12,0 N / mm2 (transverse to machine direction) |
| Modulus of rupture (textured sheet) | : | 15,0 N /mm2 (machine direction=longitudinal) : 10,0 N / mm2 (transverse to machine direction) |
| Pressure strength | : | 30,0 N /mm2 (perpendicular to sheet surface) |
| Tensile strength | : | 2,0 N /mm2 (perpendicular to sheet surface) |
| Reaction to fire | : | Fire resistant, (A1 Class building material according to EN 13501-1) |
| Release of asbestosı | : | Non-asbestos |
| Release of other dangerous substances | : | None |
| Thermal expansion coefficient | : | t: 0,005 mm/Mk |
| Thermal conductivity coefficient | : | λ 0,18 W/Mk |
| Modulus of elasticity | : | 8000 N /mm2 (machine direction=longitudinal) 6000 N / mm2 (transverse to machine direction) |
| Water absorption ratio | : | < % 30 ( full saturation, including ambient moisture ) |
| Moisture in storage | : | < % 10 (subject to ambient moisture) |
| Hygrical movement | : | 0,5 mm / m (full saturation) |
| Bending radius | : | 12 m |
Composition of all natural materials, environment, nature and human friendly,
Contains no asbestos or other harmful materials,
Incombustible ( A1 class fire resistant building material according to EN 13501-1), non-melting, helps to extinguish the active fire,
No hazardous gas emission even when exposed to extreme temperatures,
Water resistant, water absorption ratio is lower than concrete buildings, safely used in humid climates,
Highly durable against heavy climatic conditions due to the raw materials content, and being autoclaved, resistant against ultraviolet rays,
Imperishable, long life, easy maintenance,
Good heat and sound insulation,
Not affected by insects harmful to woods, not inhabitable for insects,
Can be painted repeatedly with alcali-resistant exterior or interior paints,
Warm and comfortable appearance because of the wooden effect, but physically more advantageous than wood,
Can be easily processed by proper tools, easy to install,
Economical because of eliminating the plastering,
Durable against strokes and beats,
Light, can be easily handled( weight of 8mm thick sheet is approximately 11,2 kg/m2 depending on the environmental moisture)
Odorless, produces no gas harmful to human health,
Resistant against most chemical elements and animal waste,
Resistant against frost, can be used safely in coldest climatic conditions,
Can be used much more safely in any application, where similar covering materials are used,
Perfect binding to several insulation materials, so can be used as sandwich panel for multiple purposes.
